W. Matthews Camden Rd., London

Case-mounted portable microscope c. 1858

W. Matthews Camden Rd., London. Case-mounted portable microscope c. 1858

While this microscope has a coarse adjustment by rack and pinion, it lacks a formal fine adjustment. To make up for the lack of a fine adjustment, a long brass rod is attached to the pinion of the main focusing adjustment thus, effectively, increasing the radius of the pinion allowing  it to turn more slowly than it would if the knobs were used.

W. Matthews Camden Rd., London. Case-mounted portable microscope c. 1858

W. Matthews Camden Rd., London. Case-mounted portable microscope c. 1858 . Stored in the case.


An identical example is located in the Science Museum, London; it is inventoried as follows:

CHEST MICROSCOPE BY MATTHEWS
Period: 1850-1860
Origin: English. Signed: Wm Matthews/Camden Road/London
Instrument: Height overall 380; length body-tube 134.
Case/Box: Case 295x118x67.
Inventory No.: A600260.
Negative No.: B3/1 [26]


Mathews 1855 advertisement

Mathews advertisement 1855
